Elevated Hay Feeder Shelter with Loading Ramp and Storage Extension

A sturdy 16'x9' hay feeder shelter elevated on 6x6 posts with a 9' extension for storage. Features include a hinged side wall that lowers as a ramp for loading 1200lb square bales using a winch system, two feeding openings with nets, and a spacious 15'x24' storage height area beneath the shelter.

Expert 48 hours $2500
Step-by-Step Instructions
1. Site Preparation and Footings:
- Clear and level the area for the shelter.
- Dig six post holes (12" diameter, 36" deep) for 6x6 posts arranged to support the 16'x9' shelter plus 9' extension.
- Pour concrete into holes and set posts vertically. Allow concrete to cure fully.
2. Frame the Platform:
- Attach pressure-treated 2x6 beams horizontally between posts to form the 16'x9' floor frame.
- Use galvanized carriage bolts and joist hangers for secure connections.
- Add 2x6 joists spaced 16" on center across the frame.
- Secure plywood flooring over joists.
3. Build the 9' Extension Storage Area:
- Frame an extension platform adjacent to the main structure using 2x6s and 6x6 posts as needed.
- Ensure the platform height matches main shelter floor.
- Cover with plywood or leave open for storage.
4. Construct the Hinged Side Wall (Ramp):
- Frame a 16'x9' wall panel using 2x4s spaced 16" on center.
- Attach exterior plywood sheathing.
- Fix 12" heavy-duty strap hinges along one long edge to secure wall to the shelter frame.
- Install rubber bumpers on edges to protect surfaces when lowered.
5. Install the Winch System:
- Mount the commercial-grade winch securely to the shelter frame near the hinged wall.
- Attach steel cable from winch to top edge of hinged wall.
- Add cable pulleys at strategic points to guide cable smoothly.
- Install safety chains to secure the wall in upright position.
6. Build Feeding Openings:
- Cut two 48"x48" openings evenly spaced on the opposite side of the hinged wall.
- Frame openings with 2x4s for rigidity.
- Attach heavy-duty hay nets securely using nails or screws.
7. Finalize Roofing:
- Frame a sloped roof over the shelter using 2x6 rafters.
- Cover with plywood sheeting.
- Install corrugated metal roofing panels, overlapping and securing with screws.
- Ensure proper overhangs and drainage.
8. Finishing Touches:
- Apply wood sealant or exterior paint to all exposed wood surfaces.
- Check all hardware is tight.
- Test hinged wall movement and winch operation with a safe load (simulate weight).
9. Operating Instructions:
- To load bales, disengage safety chains.
- Use winch to slowly lower hinged side wall to ground, forming ramp.
- Back truck up to ramp and unload 1200lb square bale onto ramp.
- Use winch to raise hinged wall back into vertical position.
- Secure safety chains to lock hinged wall.
- Feed bales through openings with nets to keep animals safe and prevent waste.
10. Maintenance Tips:
- Regularly inspect hinges, winch, and cables for wear.
- Reapply sealant or paint annually.
- Keep feeding nets repaired and clean.
Materials
Pressure-treated 6x6 posts - 6 pcs (10 ft length)
Pressure-treated 2x6 lumber - 40 pcs (various lengths for framing)
Pressure-treated 2x4 lumber - 30 pcs (for walls, feeding openings, and ramp framing)
Exterior-grade plywood sheets - 6 pcs (4'x8')
Corrugated metal roofing panels - 8 pcs (3'x8')
Heavy-duty hinge sets (12" heavy strap hinges) - 4 pcs
Commercial-grade winch with cable and mounting hardware - 1 set (rated for 1500 lbs)
Steel angle brackets and joist hangers - as needed
Galvanized carriage bolts (3/8" x 6") and nuts - 30 pcs
Galvanized screws (3" and 2") - 5 lbs
Galvanized nails (3") - 2 lbs
Heavy-duty hay feeder nets - 2 pcs (sized for 48"x48" openings)
Safety chains and hooks - 2 sets
Concrete mix - for post footings
Wood sealant or exterior paint - 1 gallon
Rubber bumpers or stops - 4 pcs
Metal cable pulleys (rated for 1500 lbs) - 2 pcs
L-brackets and fasteners - as needed
Wood glue - 1 bottle
